60A, Dual-Phase, 0U Horizontal PDU | 12× L6-30R Outlets
This 60A, 0U horizontal PDU has 12× L6-30R outlets, a dual-phase 208/240VAC hardwire input, a switched 60A circuit breaker, and 12× 30A output breakers.
| ENCLOSURE SPECIFICATIONS | |
| EMI Rated Enclosure | No |
| Enclosure Material | Aluminium/Steel |
| Enclosure Size | 0U x 36" |
| Enclosure Style | 19in Rack Mount |
| INPUT SPECIFICATIONS | |
| Frequency | 60Hz |
| Input Breaker UL Compliance | UL 489 |
| Input Circuit Protection | 60A Switched Circuit Breaker |
| Input Voltage | 208VAC Single Phase; 240VAC Single Phase |
| Lightning Protection (MOV) | No |
| Phase | Dual Phase (line, line, ground) |
| Power Cord | N/A |
| Total Current | 60 Amps |
| Input Connector | Internal Hardwire |
| OUTPUT SPECIFICATIONS | |
| Output Banking Scheme | 1 Outlet per Circuit Breaker |
| Output Breaker UL Compliance | UL 1077 |
| Output Circuit Protection | 12 x 30A Switched Circuit Breakers |
| Output Connectors | 12 x L6-30R |
| Output Phase | Dual Phase (line, line, ground) |
| Output Voltage | Synced to Input |
| PRODUCT DETAILS | |
| Compliance | ISO 9001:2016 Quality Controlled |
| Operating Temperature | 0C - 60C |
| TAA Compliant | No |
