30A, 120/240V, 2U Rack Mount PDU | 6× L5-30R Outlets
This 30A, 2U PDU has 6× L5-30R outlets, an L5-30P inlet with a 6ft power cord, and switched outputs.
| ENCLOSURE SPECIFICATIONS | |
| EMI Rated Enclosure | No |
| Enclosure Material | Aluminium/Steel |
| Enclosure Size | 2U x 12" |
| Enclosure Style | 19in Rack Mount |
| INPUT SPECIFICATIONS | |
| Frequency | 60Hz |
| Input Breaker UL Compliance | UL 489 |
| Input Circuit Protection | Switched 30 Amp Circuit Breaker |
| Input Voltage | 120VAC Single Phase; 240VAC Single Phase |
| Lightning Protection (MOV) | No |
| Phase | Single Phase (line, neutral, ground) |
| Power Cord | 6ft SOOW |
| Total Current | 30 Amps |
| Input Connector | L5-30P |
| OUTPUT SPECIFICATIONS | |
| Output Banking Scheme | 1 Outlet per Circuit Breaker |
| Output Breaker UL Compliance | UL 1077 |
| Output Circuit Protection | 6 x 30 Amp Switched Circuit Breakers |
| Output Connectors | 6 x L5-30R |
| Output Phase | Single Phase (line, neutral, ground) |
| Output Voltage | Synced to Input |
| PRODUCT DETAILS | |
| Compliance | ISO 9001:2016 Quality Controlled; Built to Meet UL 60950-1 |
| Operating Temperature | 0C - 60C |
| TAA Compliant | No |
